Sounder Helix Coast Master

H U M M I N B I R D ®
Pack including HELIX 7G4-CXDTA (Great Depth) and COAST chart MASTER
CO M B I N É

The Coastmaster pack version France by Humminbird to enjoy the best fishing cartography, offering highly accurate mapping coverage of all French and Corsican coasts.

From easy-to-read contours to highlighted depth ranges, you'll have the tools you need to find the best fishing spots and navigate them safely.
Tides & Currents provides current speed and direction, as well as tide height and direction.

The HELIX 7G4 series offers enhanced visibility with a 1024x600 pixel HD display. The HELIX G4 Dual Spectrum CHIRP equipped with the XD probe provides an exceptional level of clarity for structure bottom reading and fish detection.
AutoChart Live software is pre-loaded to give users the ability to create detailed bathymetric mapping of the seabed. In addition to bathymetry, this feature displays vegetation variations and bottom hardness. Maps are created live on-screen as you prospect.

Supplied with SH-A04T XTREME DEPTH probe.

Dual Spectrum CHIRP: Dual Spectrum offers two search methods: wide mode for maximum coverage and narrow mode for maximum detail.

AutoChart Live: Create real-time maps of your fishing grounds. Plot depth contours. bottom hardness and vegetation as you drive your boat. with huit hours of built-in recording time.

• GPS Plotter: Yes
• Navionics + : Yes
• NMEA output: 0183. 2000
• Waterproofing: IPx7
• Function GPS: Arrival alarm. Drift alarm. Off course alarm. Map reader. Route projection line. North map orientation. Map orientation to destination. Route marker. Speed GPS
• 50KHz option: Yes
• Interface GPS: Yes
• RMS power: 50000
• Screen type: TFT Color
• Card type: Autochart Live. Humminbird Coastmaster. Humminbird Lakemaster. Micro SD. Navionics +
• Standard probe: transom (SH-A04T)
• Number of routes: 4500
• Screen diagonal: 173
• Number of tracks: 5000
• Side scan: No
• Features :

- 7" LCD Panoramic TFT 256 color Full Sun display.
- Very high-definition screen 1024x600 pixels.
- Multifunction carto GPS / sounder DS combo.
- XD 200 and 50 kHz dual-beam 20° and 74° probes.
- Dual Spectrum / CHIRP technology.
- Peak power 4000 watts (500 W RMS).
- IPx7 waterproofing.
- WAAS internal antenna GPS.
- micro SD card reader.
- Compatible Humminbird CoastMaster/LakeMaster cards. Navionics + and Autochart Live.

• Card reader : Yes
• French menu: Yes
• Sounder functions: Low battery alarm. Temperature alarm. Fish alarm. Depth alarm. Freeze frame. Screen capture. Giant numbers. Customizable data. Split screen with 2 frequencies. RTS window. Noise filters. Fish ID. Fish ID+. Navigation data history. ID Structure and Reverse. Chart reader Navionics. Grey and white lines. Menu X-Press. Built-in simulator. Water temperature. Scroll speed. Optional surface speed. Bottom speed. Zoom on bottom
• Number of colors: 256
• Power (peak): 4,000.00
• Screen resolution: 7 " = 1024 x 600 pixels
• 3D map view: No
• Antenna GPS Internal: Yes
• Number of waypoints: 2,500.00
• Number of beams: 200
• Power supply type: 10 - 20 Vdc external
• GPS Map reader: Yes
• Mounting kit: Optional (SW-TH7)
• Dimensions on stand: 270x160x100 mm
• Target separation: 650
• Integrated cartography: Contour coastline
• Built-in dimensions : 270x138x25 mm
• Water temperature: Yes
• Humminbird Autochart Live: Yes
• Total scan width: 7400
• Number of points per trace: 20,000.00
• Plastic through-probe: Option (SH-B04T)
• Probe characteristics: 200 KHz / 20° @ 10db. 50 KHz / 74° @ -10dB
• Number of navigation screens: 200
